Movement Construction
The movement is identified as a 35 ligne calibre numbered 4852. It utilizes two tandem-wound going barrels for power transmission, employing intermediate and ratchet wheels featuring wolf’s teeth.
The escapement and regulator are mounted on a navette-shaped platform secured by three screws, featuring an Earnshaw-type spring detent escapement. The assembly includes a free-sprung bi-metallic compensation balance with adjustable screws and a grey-finished steel helical spring.
Evidence for this section
- “35’’’ movement, two large tandem-wound going barrels”
- “intermediate and ratchet wheels with wolf’s teeth”
- “navette-shaped platform with Earnshaw-type spring detent escapement”
- “large free-sprung bi-metallic compensation balance with adjustable screws, large grey-finished steel helical spring”
