The Encyclopedia of Horology

Slave (electric) public clock · England

Shepherd Gate Clock

Verified

A 24-hour dial at the gate of the Royal Observatory, Greenwich, driven by electrical signals from the observatory's master clock; among the first to show Greenwich Mean Time to the public.

Technical facts

Dial
24-hour
Drive
Electrical impulses from a master clock

Historical significance

  • A 24-hour dial at the gate of the Royal Observatory, Greenwich, driven by electrical signals from the observatory's master clock; among the first to show Greenwich Mean Time to the public.

Background

The Shepherd Gate Clock was constructed by Charles Shepherd and installed at the entrance of the Royal Observatory in 1852. The project was initiated by Astronomer Royal George Airy, who sought a method to standardize time across the country using electric signalling. Designed as part of a sympathetic system, the clock was controlled by electrical pulses transmitted from a motor clock located inside the observatory building. It functioned to provide a public time signal, contributing to the increased punctuality required for business, shipping, and the expanding railway network.

Written from the encyclopedia entries listed under Sources; each statement was checked against the cited text.

Construction and mechanism

  • The clock utilizes a 24-hour analog dial.
  • Its original configuration displayed astronomical time starting at noon.
  • The clock is currently controlled by a modern quartz mechanism rather than the original system.

Later history

  • During the 20th century, the clock was recalibrated to indicate Greenwich Mean Time starting at midnight.

Photographs

Shepherd Gate 24-Hour Clock
Shepherd Gate 24-Hour Clock — Andres Rueda, CC BY 2.0. Wikimedia Commons file page
EH1220888 Royal Observatory Wall and Clock to Right of Entrance Gates
EH1220888 Royal Observatory Wall and Clock to Right of Entrance Gates — Katie Chan, CC BY-SA 3.0. Wikimedia Commons file page
Royal Observatory Wall and Clock to Right of Entrance Gates, Greenwich - Sheperd 24 Hour Gate Clock (8128342519)
Royal Observatory Wall and Clock to Right of Entrance Gates, Greenwich - Sheperd 24 Hour Gate Clock (8128342519) — Elliott Brown from Birmingham, United Kingdom, CC BY 2.0. Wikimedia Commons file page
Shepherd Gate Clock and Public Standards of Length, Greenwich
Shepherd Gate Clock and Public Standards of Length, Greenwich — .mw-parser-output .messagebox{margin:4px 0;width:auto;border-collapse:collapse;border:2px solid var(--border-color-progressive,#6485d1);background-color:var(--background-color-neutral-subtle,#fbfcff);color:var(--color-base,#202122);box-sizing:border-box;border-inline-start-width:8px}.mw-parser-output .messagebox.mbox-small{font-size:88%;line-height:1.25em}.mw-parser-output .mbox-warning,.mw-parser-output .mbox-speedy{border:2px solid var(--border-color-error,#b22222);background:var(--background-color-error-subtle,#ffdbdb);border-inline-start-width:8px}.mw-parser-output .mbox-serious,.mw-parser-output .mbox-delete,.mw-parser-output .mbox-stop{border:2px solid var(--border-color-error,#b22222);border-inline-start-width:8px}.mw-parser-output .mbox-issue,.mw-parser-output .mbox-content{border:2px solid #f28500;background:var(--background-color-warning-subtle,#ffe);border-inline-start-width:8px}.mw-parser-output .mbox-query,.mw-parser-output .mbox-style{border:2px solid #f4c430;background:var(--background-color-warning-subtle,#ffe);border-inline-start-width:8px}.mw-parser-output .mbox-shit{border:2px solid #960;border-inline-start-width:8px}.mw-parser-output .mbox-license{border:2px solid #88a;border-inline-start-width:initial}.mw-parser-output .mbox-legal{border:2px solid var(--border-color-notice,#666);background:var(--background-color-base,#fff);border-inline-start-width:8px}.mw-parser-output .mbox-honor{border:2px solid #ca3;background:var(--background-color-warning-subtle,#fcf4db);border-inline-start-width:8px}.mw-parser-output .mbox-growth{border:2px solid #8d4;background:var(--background-color-success-subtle,#d5fdf4);border-inline-start-width:8px}.mw-parser-output .mbox-move{border:2px solid #93c;border-inline-start-width:8px}.mw-parser-output .mbox-protection,.mw-parser-output .mbox-message{border:2px solid var(--border-color-base,#aaa);border-inline-start-width:8px}.mw-parser-output .messagebox .mbox-text{border:none;padding:0.25em 0.9em;width:100%}.mw-parser-output .messagebox .mbox-image{border:none;padding-top:2px;padding-bottom:2px;padding-inline-start:0.9em;padding-inline-end:0;text-align:center}.mw-parser-output .messagebox .mbox-imageright{border:none;padding-top:2px;padding-bottom:2px;padding-inline-start:0;padding-inline-end:0.9em;text-align:center}.mw-parser-output .messagebox .mbox-empty-cell{border:none;padding:0;width:1px}.mw-parser-output .messagebox .mbox-invalid-type{text-align:center}@media(min-width:720px){.mw-parser-output .messagebox{margin:4px 10%}.mw-parser-output .messagebox.mbox-small{clear:right;float:right;margin:4px 0 4px 1em;width:238px}}body.skin--responsive .mw-parser-output table.messagebox img{max-width:none!important}Please respect the Creative Commons Attribution-ShareAlike license that this image is released under. You must use the same license if you share this image and include this credit line wherever you use this image: Y.ssk / Wikimedia Commons / CC BY-SA 4.0 While not required, if you use this image outside of the Wikimedia projects, I would appreciate it if you could leave a quick message on my talk page., CC BY-SA 4.0. Wikimedia Commons file page

Photographs are illustrative examples of the type, not necessarily the exact object described. Verify details against the source file page.

Sources & references

  1. Shepherd Gate Clock, Wikipedia (English), retrieved 2026-10-28 (text CC BY-SA 4.0)
  2. Royal Museums Greenwich, notes on the Shepherd Gate Clock

Where sources disagree, the disagreement is stated rather than resolved silently.
