The Encyclopedia of Horology

Movement record · Switzerland

Omega 321

Partially verified

Column wheel

Compare this calibre with others →

Technical specifications

Diameter
27.0 mm
Height
6.7 mm
Jewels
17
Frequency
18000 vph
Power reserve
44 h
Winding
Manual
Setting
Stem
Escapement
Lever
Balance
Screw
Complications
Chronograph, Column-wheel chronograph

Identification features

  • Column wheel, lateral clutch
  • Three registers: running seconds, 30-minute and 12-hour counters
  • Vintage examples of the calibre typically feature a copper-coloured finish on the movement plates.
  • Column-wheel chronograph control visible when the movement is opened
  • Lemania-derived bridge architecture
  • The movement is characterized by a column wheel control mechanism.
  • The movement uses a U-shaped bridge to hold down the chronograph wheels.

Known variants

  • Lemania 2310 (base ébauche)
  • Patek Philippe CH 27-70 and Vacheron Constantin chronographs derive from the same base
  • Modern re-edition of calibre 321 (2019)
  • Pre- and post-war Lemania-derived variants used across several brands

Servicing notes

Cleaning, lubrication, mainspring and pivot work belong with a qualified watchmaker working from calibre-specific documentation. Conserve original parts: replacing a worn component with a modern substitute changes the object, and refinishing plates or dials destroys evidence.

General guidance only. Antique movements should be serviced by a qualified watchmaker.

Historical significance

Lemania-based, column-wheel manual chronograph used in the early Omega Speedmaster, including the watches flight-qualified by NASA in 1965; replaced by the cam-operated calibre 861 from 1968 and later revived by Omega.

The Omega 321 was developed in collaboration with Lemania and introduced in 1942 as the 27 CHRO C12, eventually being renamed by Omega in 1949. Featuring a column-wheel design, the movement was utilized in early Omega Speedmaster models, including those worn by astronauts during the Apollo moon landings. The movement was produced until 1968, when it was replaced by the cam-operated calibre 861, before Omega revived the movement through a ground-up re-engineering project in 2019.

The added history summarises the open references listed under Sources; each statement was checked against the cited passage.

Photographs

Omega Cal. 321 Chronograph movement
Omega Cal. 321 Chronograph movement — Shane Lin, CC BY-SA 2.0. Wikimedia Commons file page
Omega Cal. 1861 Chronograph Movement
Omega Cal. 1861 Chronograph Movement — Shane Lin, CC BY-SA 2.0. Wikimedia Commons file page
Omega Cal. 321 Chronograph movement (detail)
Omega Cal. 321 Chronograph movement (detail) — Shane Lin, CC BY-SA 2.0. Wikimedia Commons file page
Omega Cal. 321 Chronograph movement (detail N.2)
Omega Cal. 321 Chronograph movement (detail N.2) — Shane Lin, CC BY-SA 2.0. Wikimedia Commons file page
Omega 321 | La Clinique Horlogère, Service et vente de montres ...
Omega 321 | La Clinique Horlogère, Service et vente de montres ... — cliniquehorlogere.ch, Rights unverified — web image search result, review pending. Web page (cliniquehorlogere.ch)
Omega - chrono 1944/45 steel case, Omega 321 caliber exc+++ - Catawiki
Omega - chrono 1944/45 steel case, Omega 321 caliber exc+++ - Catawiki — catawiki.com, Rights unverified — web image search result, review pending. Web page (catawiki.com)
Omega Chronometer Megaquartz f4.19 MHz
Omega Chronometer Megaquartz f4.19 MHz — Omega-collector, CC BY-SA 4.0. Wikimedia Commons file page
Omega 1511 and 1516 movement
Omega 1511 and 1516 movement — Omega-collector, CC BY-SA 4.0. Wikimedia Commons file page
The Best There Ever Was — Omega Calibre 321, the #MoonCalibre ...
The Best There Ever Was — Omega Calibre 321, the #MoonCalibre ... — revolutionwatch.com, Rights unverified — web image search result, review pending. Web page (revolutionwatch.com)
Omega 321 Movement | Omega Relaunches Omega Calibre 321 That Powered ...
Omega 321 Movement | Omega Relaunches Omega Calibre 321 That Powered ... — avatar.crnfrd.co.uk, Rights unverified — web image search result, review pending. Web page (avatar.crnfrd.co.uk)
OMEGA Calibre 321 Chronograph: The Rebirth of The Very First ...
OMEGA Calibre 321 Chronograph: The Rebirth of The Very First ... — swisswatches-magazine.com, Rights unverified — web image search result, review pending. Web page (swisswatches-magazine.com)

Photographs are illustrative examples of the type, not necessarily the exact object described. Verify details against the source file page.

Sources & references

  1. The Amazing Lemania Chronograph Calibre 2310, revolutionwatch.com, retrieved 2026-11-04 (paraphrased; text © the publisher)
  2. Omega 321: The Speedmaster Calibre, Vintage Guide and Parts, watchbreaker.com, retrieved 2026-11-04 (paraphrased; text © the publisher)
  3. de Carle, D., Watch and Clock Encyclopedia
  4. Period trade material catalogues and calibre reference compilations (edition-dependent)
  5. Published manufacturer technical documentation where available
  6. Omega historical and museum literature
  7. NASA equipment qualification records as cited in secondary histories

Where sources disagree, the disagreement is stated rather than resolved silently.
